The HD CMOS sensor has a size of 1/2.8-inch and a resolution of 2.14 megapixels.
There are multiple models available for the optical zoom lens, including 12x and 20x.
Simultaneous video output is supported through SDI, HDMI, network, and USB3.0.
| default |
| Model |
D6284 |
| Image Sensor |
1/2.8-inch CMOS, 2.14 megapixels |
| Focal Length |
f=4.7mm~94mm |
| White Balance |
Auto, Manual, One-Push, Auto Track, Static Color Temperature |
| Iris |
F1.6~F3.5 |
| Digital Noise Reduction |
2D/3D |
| Field of View |
59.5°~2.9° |
| S/N Ratio |
≥50dB |
| Backlight Compensation |
Support |
| Gain |
Auto, Manual |
| Menu |
English/Chinese |
| Optical Zoom |
20x |
| Wide Dynamic |
Support |
| Focusing System |
Auto, Manual, One-Push, PTZ-Triggered |
| Exposure Control |
Auto, Manual, Shutter Priority, Iris Priority, Brightness Priority |
