High quality imaging with 2 MP, 1920 × 1080 resolution
24/7 color imaging with F1.0 aperture
3D DNR technology delivers clean and sharp images
2.8 mm, 3.6 mm, 6 mmfixed focal lens
Up to 20 m white light distance for bright night imaging
One port for four switchable signals (TVI/AHD/CVI/CVBS)
Water and dust resistant (IP67)
| default |
| Communication |
HIKVISION-C |
| Weight |
Approx. 320 g (0.71 lb) |
| Lens Mount |
M12 |
| Image Sensor |
2 MP CMOS |
| Min. Illumination |
0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 75°, rotation: 0° to 360° |
| Power |
12 VDC ± 25%, Max. 2.4 W *You are recommended to use one power adapter to supply the power for one camera. |
| Material |
Metal |
| Protection |
IP67 |
| Language |
English |
| Dimension |
Φ 85.1 mm × 77.62 mm (Φ 3.35" × 3.05") |
| Lens Type |
2.8 mm, 3.6 mm, 6 mm fixed focal lens |
| Frame Rate |
TVI: 1080p@25fps/30fps CVI: 1080p@25fps/30fps AHD: 1080p@25fps/30fps CVBS: PAL/NTSC |
| Shutter Time |
PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s |
| Video Output |
Switchable TVI/AHD/CVI/CVBS |
| Signal System |
PAL/NTSC |
| White Balance |
Auto/Manual |
| Day/Night Mode |
Color |
| Image Settings |
Brightness, Mirror, Sharpness, Anti-Banding, AGC |
| Max. Resolution |
1920 (H) × 1080 (V) |
| Image Enhancement |
DWDR, BLC, HLC, Global |
| Focal Length & FOV |
2.8 mm, horizontal FOV: 98°, vertical FOV: 51°, diagonal FOV: 115° 3.6 mm, horizontal FOV: 76°, vertical FOV: 41°, diagonal FOV: 90° 6 mm, horizontal FOV: 50°, vertical FOV: 27°, diagonal FOV |
| Operating Condition |
-40°C to 60°C (-40°F to140°F), Humidity: 90% or less (non-condensing) |
| Supplement Light Type |
White Light |
| Supplement Light Range |
Up to 20 m |
| Wide Dynamic Range (WDR) |
Digital WDR |
| Light Alarm |
Solid Light Alarm (White Light) |
| Noise Reduction |
3D DNR/2D DNR |
| Smart Supplement Light |
Yes |
| Image Parameters Switch |
STD/HIGH-SAT/HIGHLIGHT |
