2 MP CMOS
High quality imaging with 1920 × 1080 resolution
3.1 mm to 15.5 mm varifocal lens, auto focus
Min. Illumination: 0.1 Lux @ (F1.2, AGC ON)
| default |
| Weight |
Approx. 925 g (2.04 lb.) |
| Image Sensor |
2 MP CMOS |
| Power Supply |
DC12V±10% |
| Min. Illumination |
0.1 Lux @ (F1.2, AGC ON) |
| Angle Adjustment |
Pan: -170° to 160°, Tilt:-28° to 28° |
| Wide Dynamic Range |
≥120 dB |
| Dimension |
145.3 mm × 145.6 mm × 145.8 mm (5.7" × 5.7" × 5.7") |
| Consumption |
5.7 W MAX |
| Day & Night |
Color |
| Shutter Time |
PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s |
| Signal System |
PAL/NTSC |
| Max. Resolution |
1920 (H) × 1080 (V) |
| Operating Conditions |
-10℃ to 50℃ (-40°F to 122°F); Humidity: 90% or less (non-condensing) |
| Lens |
3.1 mm to 15.5 mm varifocal lens |
| Field of View |
Horizontal FOV: 84.9° to 20.8° Vertical FOV: 92.8° to 23.8° Diagonal FOV: 94° to 23.8° |
| Cable length |
4.5 m |
| Pickup Distance |
5 m |
