2 MP CMOS
High quality imaging with 1920 × 1080 resolution
Low-distortion lens
Min. illumination: 0.1 Lux @ (F1.2, AGC ON)
| default |
| Weight |
Approx. 140 g (0.31 lb) |
| Lens Mount |
M8 |
| Image Sensor |
2 MP CMOS |
| Power Supply |
DC 5V ± 15% (USB) |
| Min. Illumination |
0.1 Lux @ (F1.2, AGC ON) |
| Angle Adjustment |
pan: 0°; tilt: -10° to 30°; ratation: 0° |
| Dimension |
118 mm × 46.8 mm × 54.9 mm (4.65" × 1.84" × 2.16") |
| Consumption |
Max. 1.0 W |
| Day & Night |
Color |
| Shutter Time |
PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s |
| Signal System |
PAL/NTSC |
| Operating Conditions |
-10°C to 40°C, Humidity: 90% or less (non-condensing) |
| Lens |
3.6 mm fixed focal lens |
| Field of View |
horizontal FOV: 86°, vertical FOV: 55°, diagonal FOV: 95° |
| Resolution |
1920 (H) × 1080 (V) |
| Cable length |
2 m |
| Depth of Field |
0.4 m to ∞ |
